Gallery of Audio Products
TM-1001 Power Supply Upgrade Board Assembly. Provides a precision, high reliability replacement Power Supply board for your tuner. Includes Auto-Magic circuits from the original power supply board as well as a high quality final output amplifier to improve the audio quality of your tuner.
Miniature 900 MHz 8 Channel Wireless Microphone Transmitter Miniature 900 Mhz 8 channel high quality wireless microphone transmitter with compression. Utilizes Analog Devices components for high performance audio applications, Over 10 hour battery life utilizing the the rechargeable Lithium Polymer battery shown.
900 MHz Dual Channel Wireless Microphone Receiver 900 Mhz 2 channel high quality wireless microphone receiver with single ended and balanced XLR outputs.
Phase Linear PL400 Series 1 Amplifier with replacement LED Light Board. This version was built with Blue high intensity, wide dispersion LEDs. Upgrade LED meter light boards for your equipment. Replace the original incandescent bulb based board with a long life, blue or white LED based board that saves power and reduces heat. It also gives your meters that great blue Marantz or McIntosh look.
Phase Linear PL700B LED Light Board Shown Installed and in Operation. Upgrade LED meter light boards for your equipment. Replace the original incandescent bulb based board with a long life, blue or white LED based board that saves power and reduces heat. It also gives your meters that great blue Marantz or McIntosh look.
Realistic TM-1001 AM-FM Tuner Light board Front View (on top). Original TM-1001 light board (on bottom) Upgrade LED meter light boards for the TM-1001 Tuner. Replace the original incandescent bulb based board with a long life, blue or white LED based board that saves power and reduces heat. It also gives your meters that great blue Marantz or McIntosh look. The board assembly is an exact drop in and uses the original plastic snap in hardware that held the original board in place. The replacement board is a high quality FR-4 double-sided glass-epoxy PC board vs. the original single-sided phenolic board.
Realistic TM-1001 AM-FM Tuner Light board Back View (on top). Original TM-1001 light board (on bottom) The replacement board employs a full wave bridge rectifier and filter caps to provide reliable LED illuminaton for the TM-1001 meters. The replacement light board utilizes 6 LEDs for even illumination of the meters.
TM-1001 Light Board Shown Installed and in Operation
Phase Linear PL700B Amplifier LED Light Board Upgrade your original incandescent light board with long life LED illumination for both the meters and logo. Choose white or blue LED illumination for the meters.
Phase Linear PL400 LED Light Shown Installed and in Operation.
TM-1001 with replacement Light Board This version was built with Blue high intensity LEDs.
